MSS1246-223MLC Inductor, 22UH, 3.4A, 20%, Pwr, 18MHZ COILCRAFT

COILCRAFTUGS :MSS1246-223MLC Code de commande:2288360

Prix:
Prix ​​promotionnel€3,13

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (24 unité)

Documenten en downloads

description

COILCRAFT - MSS1246-223MLC - Power Inductor (SMD), 22 µH, 3.4 A, Shielded, 3.76 A, MSS1246, 12mm x 12mm x 4.6mm

  • Inductance: 22µH
  • RMS Current (Irms): 3.4A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 3.76A
  • Product Range: MSS1246 Series
  • Power Inductor Case: 12mm x 12mm x 4.6mm
  • DC Resistance Max: 0.067ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 18MHz
