COILCRAFT - MSS1260T-104MLB - Power Inductor (SMD), 100 µH, 2.1 A, Shielded, 2.06 A, MSS1260T, 12.3mm x 12.3mm x 6mm
- Inductance: 100µH
- RMS Current (Irms): 2.1A
- Inductor Construction: Shielded
- Saturation Current (Isat): 2.06A
- Product Range: MSS1260T Series
- Power Inductor Case: 12.3mm x 12.3mm x 6mm
- DC Resistance Max: 0.146ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 7.8MHz
