COILCRAFT - MSS1260T-332NLD - Power Inductor (SMD), 3.3 µH, 7 A, Shielded, 10.88 A, MSS1260T, 12.3mm x 12.3mm x 6mm
- Inductance: 3.3µH
- RMS Current (Irms): 7A
- Inductor Construction: Shielded
- Saturation Current (Isat): 10.88A
- Product Range: MSS1260T Series
- Power Inductor Case: 12.3mm x 12.3mm x 6mm
- DC Resistance Max: 0.014ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 42MHz
