COILCRAFT - MSS1260T-563MLD - Power Inductor (SMD), 56 µH, 2.4 A, Shielded, 2.64 A, MSS1260T, 12.3mm x 12.3mm x 6mm
- Inductance: 56µH
- RMS Current (Irms): 2.4A
- Inductor Construction: Shielded
- Saturation Current (Isat): 2.64A
- Product Range: MSS1260T Series
- Power Inductor Case: 12.3mm x 12.3mm x 6mm
- DC Resistance Max: 0.089ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 10.5MHz
