COILCRAFT - MSS1278-224KLD - Power Inductor (SMD), 220 µH, 1.6 A, Shielded, 1.96 A, MSS1278, 12.3mm x 12.3mm x 8.05mm
- Inductance: 220µH
- RMS Current (Irms): 1.6A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.96A
- Product Range: MSS1278 Series
- Power Inductor Case: 12.3mm x 12.3mm x 8.05mm
- DC Resistance Max: 0.3596ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Reel Quantity: 500
- Self Resonant Frequency Min: 3.4MHz
