COILCRAFT - MSS1278T-142NLD - Power Inductor (SMD), 1.4 µH, 9.8 A, Shielded, 25.04 A, MSS1278T, 12mm x 12mm x 7.8mm
- Inductance: 1.4µH
- RMS Current (Irms): 9.8A
- Inductor Construction: Shielded
- Saturation Current (Isat): 25.04A
- Product Range: MSS1278T Series
- Power Inductor Case: 12mm x 12mm x 7.8mm
- DC Resistance Max: 0.0098ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 85MHz
