COILCRAFT - MSS1278T-222NLD - Power Inductor (SMD), 2.2 µH, 9.2 A, Shielded, 22.56 A, MSS1278T, 12mm x 12mm x 7.8mm
- Inductance: 2.2µH
- RMS Current (Irms): 9.2A
- Inductor Construction: Shielded
- Saturation Current (Isat): 22.56A
- Product Range: MSS1278T Series
- Power Inductor Case: 12mm x 12mm x 7.8mm
- DC Resistance Max: 0.0105ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Reel Quantity: 500
- Self Resonant Frequency Min: 60MHz
