COILCRAFT - MSS1278T-562MLD - Power Inductor (SMD), 5.6 µH, 6.2 A, Shielded, 13.38 A, MSS1278T, 12mm x 12mm x 7.8mm
- Inductance: 5.6µH
- RMS Current (Irms): 6.2A
- Inductor Construction: Shielded
- Saturation Current (Isat): 13.38A
- Product Range: MSS1278T Series
- Power Inductor Case: 12mm x 12mm x 7.8mm
- DC Resistance Max: 0.0175ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 30MHz
