COILCRAFT - MSS5131-562MLC - Power Inductor (SMD), 5.6 µH, 2.3 A, Shielded, 1 A, MSS5131, 5.1mm x 5.1mm x 3.1mm
- Inductance: 5.6µH
- RMS Current (Irms): 2.3A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1A
- Product Range: MSS5131 Series
- Power Inductor Case: 5.1mm x 5.1mm x 3.1mm
- DC Resistance Max: 0.042ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 44MHz
