COILCRAFT - MSS6122-153MLC - Power Inductor (SMD), 15 µH, 1.5 A, Shielded, 850 mA, MSS6122
- Inductance: 15µH
- RMS Current (Irms): 1.5A
- Inductor Construction: Shielded
- Saturation Current (Isat): 850mA
- Product Range: MSS6122 Series
- Power Inductor Case: 6.1mm x 6.1mm x 2.2mm
- DC Resistance Max: 0.21ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 38MHz
