PHOENIX CONTACT - MSTB 2,5/14-ST-5,08-LR - Pluggable Terminal Block, 5.08 mm, 14 Ways, 24AWG to 12AWG, 2.5 mm², Screw, 12 A
- Pitch Spacing: 5.08mm
- No. of Positions: 14Ways
- Wire Size (AWG): 24AWG to 12AWG
- Conductor Area CSA: 2.5mm²
- Wire Connection Method: Screw
- Rated Current: 12A
- Rated Voltage: 320V
- Product Range: MSTB
- SVHC: No SVHC (15-Jan-2018)
- Connector Mounting: Cable Mount
- Connector Type: Terminal Block, Pluggable
- Contact Plating: Tin Plated Contacts
- Wire Size AWG Max: 12AWG
- Wire Size AWG Min: 24AWG
