MURATA POWER SOLUTIONS - MTC1S1205MC-R7 - Isolated Surface Mount DC/DC Converter, Medical, 2:1, 1 W, 1 Output, 5 V, 200 mA
- No. of Outputs: 1 Output
- Output Power Max: 1W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 200mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: MTC1 Series
- Input Voltage DC Min: 9V
- Input Voltage DC Max: 18V
- DC / DC Converter Output Type: Fixed, Adjustable
- DC / DC Converter Type: Module
- DC / DC Converter Mounting: Surface Mount Device
- Width: 14.22mm
- Height: 11.23mm
- Depth: 14.99mm
- SVHC: No SVHC (07-Jul-2017)
- Approvals & Standards: UL
