OJ-Sh-105LM,000 Relay, SPST-NO, 250VAC, 30Vdc, 3a OEG - Te Connectivity

OEG - TE CONNECTIVITYUGS :1461404-1 Code de commande:1891678

Prix:
Prix ​​promotionnel€3,36

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (553 unité)

Documents et téléchargements

description

OEG - TE CONNECTIVITY - 1461404-1 - General Purpose Relay, OJ Series, Power, Non Latching, SPST-NO, 5 VDC, 3 A

  • Contact Configuration: SPST-NO
  • Coil Voltage: 5VDC
  • Contact Current: 3A
  • Product Range: OJ Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 30VDC
  • Contact Material: Silver
  • Coil Resistance: 125ohm
  • SVHC: No SVHC (15-Jan-2018)
  • Approvals & Standards: VDE
  • Coil Voltage VDC Nom: 5V
  • Contact Current Max: 3A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 30V
  • External Depth: 18.2mm
  • External Height: 14.7mm
  • External Width: 10.2mm
  • Nom Operating Power: 200mW
  • Relay Type: Power
