BOURNS - PWR263S-20-1000J - SMD Chip Resistor, 100 ohm, ± 5%, 20 W, TO-263 (D2PAK), Thick Film, High Power
- Resistor Case Style: TO-263 (D2PAK)
- Resistance: 100ohm
- Product Range: PWR263 Series
- Voltage Rating: 250V
- Resistor Element Material: Thick Film
- Power Rating: 20W
- Resistance Tolerance: ± 5%
- Temperature Coefficient: ± 100ppm/°C
- Automotive Qualification Standard: AEC-Q200
- SVHC: Lead (15-Jan-2019)
- External Depth: 10.4mm
- External Length / Height: 4.5mm
- External Width: 10.1mm
- Operating Temperature Max: 155°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +155°C
- Resistor Mounting: Surface Mount Device
