PX0796/S Socket, Panel, 12WAY Bulgin Limited

BULGIN LIMITEDUGS :PX0796/S Code de commande:8406812

Prix:
Prix ​​promotionnel€49,46

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (38 unité)

Documents et téléchargements

description

BULGIN LIMITED - PX0796/S - Circular Connector, Buccaneer Standard Series, Panel Mount Receptacle, 12 Contacts, Screw Socket

  • Product Range: Buccaneer Standard Series
  • Circular Connector Shell Style: Panel Mount Receptacle
  • No. of Contacts: 12Contacts
  • Circular Contact Type: Screw Socket
  • Coupling Style: -
  • Connector Body Material: Nylon (Polyamide), Glass Filled Body
  • Connector Body Plating: -
  • Contact Material: -
  • Contact Plating: -
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: CSA, UL, VDE
  • Cable Diameter Max: 8.1mm
  • Cable Diameter Min: 6mm
  • Colour: Black
  • Connector Mounting: Panel Mount
  • Connector Type: Circular Industrial
  • Contact Gender: Socket
  • Contact Resistance Max: 5mohm
  • Current Rating: 5A
  • Flammability Rating: UL94V-0
  • Gender: Receptacle
  • IP / NEMA Rating: IP68
  • Insulation Resistance: 100Mohm
  • No. of Positions: 12Ways
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -20°C
  • Voltage Rating V DC: 50V
  • Voltage Rating VAC: 50V
  • Working Voltage: 50V
