POTTER&BRUMFIELD - TE CONNECTIVITY - R10-E1Y4-V700 - General Purpose Relay, R10 Series, Power, Non Latching, 4PDT, 24 VDC, 2 A
- Contact Configuration: 4PDT
- Coil Voltage: 24VDC
- Contact Current: 2A
- Product Range: R10 Series
- Relay Mounting: Socket
- Coil Type: Non Latching
- Contact Voltage VAC: 120VAC
- Relay Terminals: Quick Connect
- Contact Voltage VDC: 28VDC
- Contact Material: Silver
- Coil Resistance: 700ohm
- Approval Bodies: CSA
- Approval Category: UL Recognised
- Approvals & Standards: CSA
- Case Material: Polycarbonate
- Coil Voltage VDC Nom: 24V
- Contact Current Max: 3A
- Contact Current Rating: 3A
- Contact Voltage AC Nom: 240V
- Contact Voltage DC Nom: 28V
- DC Coil Power: 500mW
- Dielectric Voltage Coil to Contact: 1000VAC
- Dielectric Voltage Contact to Contact: 1000VAC
- External Depth: 18.67mm
- External Height: 30.15mm
- External Length / Height: 30.15mm
- External Width: 24.13mm
- Must Actuate Voltage: 18VDC
- Nom Operating Power: 500mW
- Operating Temperature Max: 75°C
- Operating Temperature Min: -55°C
- Relay Type: Power - General Purpose
- Switching Voltage AC: 115VAC
- Switching Voltage DC: 28VDC
- Type: Non-sealed
