R46KR422050M2K Cap, 2.2µF, 10%, PP, Radial Kemet

KEMETUGS :R46KR422050M2K Code de commande:1679323

Prix:
Prix ​​promotionnel€4,41

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (2687 unité)

Documents et téléchargements

description

KEMET - R46KR422050M2K - Safety Capacitor, Metallized PP, Radial Box - 2 Pin, 2.2 µF, ± 10%, X2, Through Hole

  • Capacitance: 2.2µF
  • Suppression Class: X2
  • Product Range: R46 275V Series
  • Voltage Rating X: 275V
  • Voltage Rating Y: -
  • Capacitor Dielectric Type: PP (Polypropylene)
  • Capacitance Tolerance: ± 10%
  • dv/dt Rating: 150V/µs
  • Capacitor Case Style: Radial Box
  • Capacitor Terminals: Radial Leaded
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 110°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Tolerance ±: ± 10%
  • Capacitor Application: General Purpose
  • Capacitor Mounting: Through Hole
  • External Depth: 13mm
  • External Length / Height: 25mm
  • External Width: 32mm
  • Height: 25mm
  • Lead Length: 25mm
  • Lead Spacing: 27.5mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +110°C
  • Voltage Rating VAC: 275V
