TE CONNECTIVITY - 2-1416010-6 - General Purpose Relay, RE Series, Power, Non Latching, SPST-NO, 12 VDC, 6 A
- Contact Configuration: SPST-NO
- Coil Voltage: 12VDC
- Contact Current: 6A
- Product Range: RE Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 720ohm
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: VDE
- Approval Category: UL Recognised
- Coil Voltage VDC Nom: 12V
- Contact Current AC Max: 6A
- Contact Current DC Max: 6A
- Contact Current Max: 6A
- Contact Voltage AC Nom: 240V
- DC Coil Power: 200mW
- Dielectric Voltage Coil to Contact: 4000V
- Dielectric Voltage Contact to Contact: 1000V
- External Depth: 10mm
- External Height: 10.6mm
- External Length / Height: 10.6mm
- External Width: 20mm
- Nom Operating Power: 200mW
- Operating Temperature Max: 70°C
- Operating Temperature Min: -40°C
- Operating Time: 5ms
- Relay Type: Power
- Release Time: 1ms
- Switching Voltage AC / DC Max: 400VAC
- Voltage Rating VAC: 240VAC
