SCHRACK - TE CONNECTIVITY - 3-1393240-6 - Power Relay, SPST-NO, 48 VDC, 16 A, RT1, Through Hole, Non Latching
- Contact Configuration: SPST-NO
- Coil Voltage: 48VDC
- Contact Current: 16A
- Product Range: RT1 Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250V
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Tin Oxide
- Coil Resistance: 5.52kohm
- SVHC: No SVHC (15-Jan-2019)
- Approvals & Standards: CSA, UL
