SCHNEIDER ELECTRIC - RXM4AB2JD - General Purpose Relay, Zelio RXM Series, Power, 4PDT, 12 VDC, 6 A
- Contact Configuration: 4PDT
- Coil Voltage: 12VDC
- Contact Current: 6A
- Product Range: Zelio RXM Series
- Relay Mounting: Socket
- Coil Type: -
- Contact Voltage VAC: 250VAC
- Relay Terminals: Quick Connect
- Contact Voltage VDC: 250VDC
- Contact Material: Silver
- Coil Resistance: 160ohm
- SVHC: No SVHC (15-Jan-2018)
- Approvals & Standards: CSA, IEC, UL
- Coil Voltage VDC Nom: 12V
- Contact Current Max: 6A
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Nom: 250V
- External Depth: 27mm
- External Height: 40mm
- External Width: 21mm
- Relay Type: Power - General Purpose
