TE CONNECTIVITY - 2-1415899-3 - General Purpose Relay, RZ Series, Power, Non Latching, SPDT, 24 VDC, 16 A
- Contact Configuration: SPDT
- Coil Voltage: 24VDC
- Contact Current: 16A
- Product Range: RZ Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Tin Oxide
- Coil Resistance: 1.44kohm
- SVHC: No SVHC (27-Jun-2018)
- Coil Voltage VDC Nom: 24V
- Contact Current AC Max: 16A
- Contact Current Max: 16A
- Contact Voltage AC Nom: 250V
- External Depth: 12.7mm
- External Height: 15.7mm
- External Length / Height: 15.7mm
- External Width: 29mm
- Nom Operating Power: 400mW
- Relay Type: Power
- Termination Type: Through Hole
