ABB - S201MC0.5 - Thermal Magnetic Circuit Breaker, C Curve, S200M, 500 mA, 1 Pole, 230 VAC, DIN Rail
- Product Range: S200M Series
- Current Rating: 500mA
- No. of Poles: 1 Pole
- Voltage Rating V DC: -
- Voltage Rating VAC: 230VAC
- Circuit Breaker Mounting: DIN Rail
- Approval Bodies: CSA, EN, IEC, IEC, UL, VDE
- Breaking Capacity Current AC: 10kA
- External Depth: 69mm
- External Length / Height: 85mm
- External Width: 17.5mm
- No. of Electrical Operations: 20000
- No. of Mechanical Operations: 20000
- Operating Temperature Max: 55°C
- Operating Temperature Min: -25°C
- Tripping Characteristic: C
