SENSATA / CYNERGY3 - SAR92405 - Reed Relay, SPST-NO, 24 VDC, S, Through Hole, 1 kohm, 500 mA
- Contact Configuration: SPST-NO
- Coil Voltage: 24VDC
- Product Range: S Series
- Relay Mounting: Through Hole
- Coil Resistance: 1kohm
- Switching Current Max: 500mA
- Switching Voltage Max: 20V
- SVHC: No SVHC (17-Dec-2015)
- Coil Voltage VDC Nom: 24V
- External Depth: 27.6mm
- External Height: 8.5mm
- External Width: 7.3mm
- Operating Temperature Max: 70°C
- Operating Temperature Min: -20°C
- Operating Time: 1ms
- Release Time: 0.5ms
- Switch Power Max: 10W
