COILCRAFT - SER8052-802MEC - Power Inductor (SMD), 8 µH, 6.31 A, Shielded, 2.9 A, SER80xx, 8.8mm x 8.5mm x 5.2mm
- Inductance: 8µH
- RMS Current (Irms): 6.31A
- Inductor Construction: Shielded
- Saturation Current (Isat): 2.9A
- Product Range: SER80xx Series
- Power Inductor Case: 8.8mm x 8.5mm x 5.2mm
- DC Resistance Max: 0.01433ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Self Resonant Frequency Min: 43MHz
