SPC 5/2-STCL-7.62 Terminal Block, Pluggable, 2Pos, 8AWG Phoenix Contact

PHOENIX CONTACTUGS :SPC 5/2-STCL-7.62 Code de commande:1793636

Prix:
Prix ​​promotionnel€5,53

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (71 unité)

Documents et téléchargements

description

PHOENIX CONTACT - SPC 5/2-STCL-7.62 - Pluggable Terminal Block, 7.62 mm, 2 Ways, 24AWG to 8AWG, 10 mm², Push In, 41 A

  • Pitch Spacing: 7.62mm
  • No. of Positions: 2Ways
  • Wire Size (AWG): 24AWG to 8AWG
  • Conductor Area CSA: 10mm²
  • Wire Connection Method: Push In
  • Rated Current: 41A
  • Rated Voltage: 1kV
  • Product Range: SPC Series
  • SVHC: No SVHC (15-Jan-2018)
  • Connector Mounting: PCB Mount
  • Connector Type: Terminal Block, PCB
  • Contact Material: Copper
  • Contact Plating: Tin Plated Contacts
  • Voltage Rating VAC: 1000V
  • Wire Area Size Max: 10mm²
  • Wire Area Size Min: 0.2mm²
  • Wire Size AWG Max: 8AWG
  • Wire Size AWG Min: 24AWG
