MULTICOMP - SPC15399 - D Sub Connector, HD44, High Density, Receptacle, 44 Contacts, DB, Solder
- No. of Contacts: 44Contacts
- Gender: Receptacle
- Contact Termination Type: Solder
- D Sub Shell Size: DB
- Product Range: -
- Connector Body Material: Metal Body
- Contact Material: Brass
- Contact Plating: Gold Plated Contacts
- SVHC: No SVHC (07-Jul-2017)
- Colour: Black
- Connector Mounting: Panel Mount, Through Hole Mount
- Contact Resistance: 15mohm
- Contact Termination: Solder
- Current Rating: 5A
- D Sub Connector Type: High Density
- Flammability Rating: UL94V-0
- Insulation Resistance: 1000Mohm
- Material: Steel
- Operating Temperature Max: 100°C
- Operating Temperature Min: -50°C
- Termination Method: Through Hole
- Withstand Voltage: 500V
