BOURNS - SRR1240-271K - Power Inductor (SMD), 270 µH, 800 mA, Shielded, 800 mA, SRR1240, 12.5mm x 12.5mm x 4mm
- Inductance: 270µH
- RMS Current (Irms): 800mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 800mA
- Product Range: SRR1240 Series
- Power Inductor Case: 12.5mm x 12.5mm x 4mm
- DC Resistance Max: 0.78ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 10
- Q Test Frequency: 796kHz
- Self Resonant Frequency Min: 6MHz
