description
BOURNS - SRR1240-561K - Power Inductor (SMD), 560 µH, 550 mA, Shielded, 520 mA, SRR1240, 12.5mm x 12.5mm x 4mm
- Inductance: 560µH
- RMS Current (Irms): 550mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 520mA
- Product Range: SRR1240 Series
- Power Inductor Case: 12.5mm x 12.5mm x 4mm
- DC Resistance Max: 1.5ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 12
- Q Test Frequency: 796kHz
- Self Resonant Frequency Min: 4MHz
