BOURNS - SRR1240-821K - Power Inductor (SMD), 820 µH, 450 mA, Shielded, 420 mA, SRR1240
- Inductance: 820µH
- RMS Current (Irms): 450mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 420mA
- Product Range: SRR1240 Series
- Power Inductor Case: 12.5mm x 12.5mm x 4mm
- DC Resistance Max: 2.4ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 10
- Q Test Frequency: 796kHz
- Self Resonant Frequency Min: 3.5MHz
