BOURNS - SRR1240-8R2M - Power Inductor (SMD), 8.2 µH, 4.5 A, Shielded, 4.3 A, SRR1240, 12.5mm x 12.5mm x 4mm
- Inductance: 8.2µH
- RMS Current (Irms): 4.5A
- Inductor Construction: Shielded
- Saturation Current (Isat): 4.3A
- Product Range: SRR1240 Series
- Power Inductor Case: 12.5mm x 12.5mm x 4mm
- DC Resistance Max: 0.027ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 10
- Q Test Frequency: 7.96MHz
- Self Resonant Frequency Min: 32MHz
