BOURNS - SRR6040A-820M - Power Inductor (SMD), 82 µH, 700 mA, Shielded, 630 mA, SRR6040A, 6.7mm x 6.7mm x 4mm
- Inductance: 82µH
- RMS Current (Irms): 700mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 630mA
- Product Range: SRR6040A Series
- Power Inductor Case: 6.7mm x 6.7mm x 4mm
- DC Resistance Max: 0.29ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- Automotive Qualification Standard: AEC-Q200
