BOURNS - SRR7032-220M - Power Inductor (SMD), 22 µH, 960 mA, Shielded, 1.05 A, SRR7032
- Inductance: 22µH
- RMS Current (Irms): 960mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.05A
- Product Range: SRR7032 Series
- Power Inductor Case: 7mm x 7mm x 3.2mm
- DC Resistance Max: 0.135ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 20
- Q Test Frequency: 2.52MHz
- Self Resonant Frequency Min: 29MHz
