BOURNS - SRR7032-221M - Power Inductor (SMD), 220 µH, 300 mA, Shielded, 320 mA, SRR7032, 7mm x 7mm x 3.2mm
- Inductance: 220µH
- RMS Current (Irms): 300mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 320mA
- Product Range: SRR7032 Series
- Power Inductor Case: 7mm x 7mm x 3.2mm
- DC Resistance Max: 1.3ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 47
- Q Test Frequency: 796kHz
- Self Resonant Frequency Min: 7.5MHz
