SS12SDP2 Slide Switch, SPDT, On-None-On NKK Switches

NKK SWITCHESUGS :SS12SDP2 Code de commande:1524325

Prix:
Prix ​​promotionnel€6,86

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1052 unité)

Documents et téléchargements

description

NKK SWITCHES - SS12SDP2 - Slide Switch, SPDT, On-None-On, Through Hole, SS, 100 mA

  • Contact Configuration: SPDT
  • Switch Operation: On-None-On
  • Switch Mounting: Through Hole
  • Product Range: SS Series
  • Contact Current Max: 100mA
  • Contact Voltage AC Max: -
  • Contact Voltage DC Max: 30V
  • Orientation: Vertical
  • SVHC: No SVHC (15-Jan-2019)
  • Actuation Type: Raised
  • Actuator Type: Raised Slide
  • Contact Current DC Max: 0.1A
  • Contact Resistance: 20mohm
  • Dielectric Strength VDC: 500VAC
  • External Depth: 4mm
  • External Length / Height: 4.5mm
  • External Width: 10.2mm
  • Insulation Resistance: 100Mohm
  • Insulation Resistance Voltage: 500VDC
  • Lead Spacing: 2.54mm
  • Lever Length: 2mm
  • No. of Electrical Operations: 10000
  • No. of Mechanical Operations: 10000
  • Operating Temperature Max: 60°C
  • Operating Temperature Min: -15°C
  • Pin Length: 3mm
  • Termination Method: Top Actuated
  • Travel: 2mm
