T92S7A12-240 Relay, DPST-NO, 277VAC, 28VDC, 40A Potter&BRUMFIELD - Te Connectivity

POTTER&BRUMFIELD - TE CONNECTIVITYUGS :T92S7A12-240 Code de commande:1608378

Prix:
Prix ​​promotionnel€27,62

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (440 unité)

Documents et téléchargements

description

POTTER&BRUMFIELD - TE CONNECTIVITY - T92S7A12-240 - General Purpose Relay, T92 Series, Power, Non Latching, DPST-NO, 240 VAC, 40 A

  • Contact Configuration: DPST-NO
  • Coil Voltage: 240VAC
  • Contact Current: 40A
  • Product Range: T92 Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 277VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 28VDC
  • Contact Material: Silver Cadmium Oxide
  • Coil Resistance: 3.8kohm
  • SVHC: Cadmium oxide (27-Jun-2018)
  • Approvals & Standards: CSA, UL, VDE
  • Coil Voltage VAC Nom: 240V
  • Contact Current AC Max: 30A
  • Contact Current Max: 40A
  • Contact Voltage AC Nom: 600V
  • Contact Voltage DC Nom: 28V
  • External Depth: 34.5mm
  • External Height: 30.7mm
  • External Length / Height: 30.7mm
  • External Width: 52.3mm
  • Nom Operating Power: 4VA
  • Relay Type: Power - General Purpose
