description
POTTER&BRUMFIELD - TE CONNECTIVITY - 1558675-8 - Power Relay, SPDT, 48 VDC, 20 A, T9G, Through Hole, Non Latching
- Contact Configuration: SPDT
- Coil Voltage: 48VDC
- Contact Current: 20A
- Product Range: T9G Series
- Relay Mounting: Panel
- Coil Type: Non Latching
- Contact Voltage VAC: 250V
- Relay Terminals: Quick Connect, Solder
- Contact Voltage VDC: -
- Contact Material: Silver Tin Oxide
- Coil Resistance: 2.56kohm
- SVHC: No SVHC (15-Jan-2018)
- Approvals & Standards: IEC, UL, VDE
