YAGEO - TC164-JR-070RL - Zero Ohm Network Resistor, Jumper, 1206 [3216 Metric], Thick Film, Isolated, Concave, 4 Resistors
- Resistance: 0ohm
- Product Range: TC164 Series
- No. of Elements: 4Elements
- Network Circuit Type: Isolated
- Resistor Case Style: 1206 [3216 Metric]
- No. of Pins: 8Pins
- Voltage Rating: 50V
- Power Rating per Element: 62.5mW
- Resistance Tolerance: -
- Temperature Coefficient: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Climatic Category: 55/125/56
- External Depth: 0.6mm
- External Length / Height: 3.2mm
- External Width: 1.6mm
- Full Power Rating Temperature: 70°C
- Operating Temperature Max: 155°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +155°C
- Power Rating: 63mW
- Reel Quantity: 5000
- Resistance R1: 0ohm
- Resistor Element Material: Thick Film
- Resistor Mounting: Surface Mount Device
- Temperature Coeff. +: 100ppm/°C
- Temperature Coeff. -: 100ppm/°C
- Voltage Rating V DC: 50V
- Voltage Rating VAC: 50V
