description
TRACO POWER - TDR 2-2423WI - Isolated Through Hole DC/DC Converter, ITE, 4:1, 2 W, 2 Output, 15 V, 67 mA
- No. of Outputs: 2 Output
- Output Power Max: 2W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 67mA
- Output Voltage - Output 2: -15V
- Output Current - Output 2: 67mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TDR 2WI Series
- Input Voltage DC Min: 9V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 12.8mm
- Height: 8.7mm
- Depth: 18.9mm
- SVHC: No SVHC (27-Jun-2018)
- Approval Bodies: cUL, EN, IEC, UL
- Approvals & Standards: IEC, UL
- Efficiency: 81%
- Isolation Voltage: 1.5kV
- No. of Outputs: 2Outputs
- Power Rating: 2W
- Supply Voltage: 24V
