TRACO POWER - TDR 3-2423SM - Isolated Surface Mount DC/DC Converter, ITE, 2:1, 3 W, 2 Output, 15 V, 100 mA
- No. of Outputs: 2 Output
- Output Power Max: 3W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 100mA
- Output Voltage - Output 2: -15V
- Output Current - Output 2: 100mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TDR 3 Series
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed, Adjustable
- DC / DC Converter Type: Surface Mount DIP
- DC / DC Converter Mounting: Surface Mount Device
- Width: 12.8mm
- Height: 8.7mm
- Depth: 18.9mm
- SVHC: No SVHC (27-Jun-2018)
- Approvals & Standards: IEC, UL
- No. of Outputs: 2Outputs
