TRACO POWER - TEC 3-1221WI - Isolated Through Hole DC/DC Converter, ITE, 4:1, 3 W, 2 Output, 5 V, 300 mA
- No. of Outputs: 2 Output
- Output Power Max: 3W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 300mA
- Output Voltage - Output 2: -5V
- Output Current - Output 2: 300mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TEC 3WI Series
- Input Voltage DC Min: 4.5V
- Input Voltage DC Max: 18V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 9.1mm
- Height: 11.2mm
- Depth: 21.8mm
- SVHC: No SVHC (27-Jun-2018)
- Approvals & Standards: EN, IEC, UL
