Tem 3-2423N DC-DC Conv, ISO POL, 2 O/P, 0.1A, 15V TRACO Power

TRACO POWER - TEM 3-2423N - Isolated Through Hole DC/DC Converter, ITE, 1:1, 3 W, 2 Output, 15 V, 100 mA

• No. of Outputs: 2 Output
• Output Power Max: 3W
• Output Voltage - Output 1: 15V
• Output Current - Output 1: 100mA
• Output Voltage - Output 2: -15V
• Output Current - Output 2: 100mA
• Output Voltage - Output 3: -
• Output Current - Output 3: -
• Product Range: TEM 3N Series
• Input Voltage DC Min: 21.6V
• Input Voltage DC Max: 26.4V
• DC / DC Converter Output Type: Fixed
• DC / DC Converter Type: DIP
• DC / DC Converter Mounting: Through Hole
• Width: 20mm
• Height: 10mm
• Depth: 32mm
• SVHC: No SVHC (27-Jun-2018)
• Approvals & Standards: CSA, IEC, UL
• No. of Outputs: 2Outputs
