Ten 20-2423WIN Converter, DC/DC, 20W, ±15V/0.7A TRACO Power

TRACO POWERUGS :TEN 20-2423WIN Code de commande:1284269

Prix:
Prix ​​promotionnel€81,80

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (35 unité)

Documents et téléchargements

description

TRACO POWER - TEN 20-2423WIN - Isolated Through Hole DC/DC Converter, ITE, 4:1, 20 W, 2 Output, 15 V, 665 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 20W
  • Output Voltage - Output 1: 15V
  • Output Current - Output 1: 665mA
  • Output Voltage - Output 2: -15V
  • Output Current - Output 2: 665mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TEN 20WIN Series
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 36V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 25.4mm
  • Height: 10.2mm
  • Depth: 50.8mm
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: IEC/EN 60950-1, UL/cUL 60950-1
  • Efficiency: 87%
  • Isolation Voltage: 1.5kV
  • Load Regulation: 1%
  • No. of Outputs: 2Outputs
  • Output Current - Max: -665mA
  • Output Ripple Voltage pk-pk: 100mV
  • Output Voltage +: +15VDC
  • Output Voltage -: -15VDC
  • Power Rating: 20W
  • Supply Voltage: 24V
