Ten 30-2411 Converter, DC DC, 30W, 5.1V, 6a TRACO Power

TRACO POWERUGS :TEN 30-2411 Code de commande:1772210

Prix:
Prix ​​promotionnel€85,72

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (94 unité)

Documents et téléchargements

description

TRACO POWER - TEN 30-2411 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 30 W, 1 Output, 5.1 V, 6 A

  • No. of Outputs: 1 Output
  • Output Power Max: 30W
  • Output Voltage - Output 1: 5.1V
  • Output Current - Output 1: 6A
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TEN 30 Series
  • Input Voltage DC Min: 18V
  • Input Voltage DC Max: 36V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 25.4mm
  • Height: 10.2mm
  • Depth: 50.8mm
  • SVHC: No SVHC (27-Jun-2018)
  • Efficiency: 90%
  • External Depth: 25.4mm
  • External Length / Height: 10.2mm
  • External Width: 50.8mm
  • Isolation Voltage: 1.5kV
  • No. of Outputs: 1Outputs
  • Power Rating: 30W
  • Power Supply Output Type: Fixed
