Ten 30-2432WIN DC/DC, 5V&±15V, 30W TRACO Power

TRACO POWERUGS :TEN 30-2432WIN Code de commande:1635238

Prix:
Prix ​​promotionnel€113,92

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (11 unité)

Documents et téléchargements

description

TRACO POWER - TEN 30-2432WIN - Isolated Through Hole DC/DC Converter, ITE, 4:1, 30 W, 3 Output, 5 V, 4 A

  • No. of Outputs: 3 Output
  • Output Power Max: 30W
  • Output Voltage - Output 1: 5V
  • Output Current - Output 1: 4A
  • Output Voltage - Output 2: 15V
  • Output Current - Output 2: 330mA
  • Output Voltage - Output 3: -15V
  • Output Current - Output 3: 330mA
  • Product Range: -
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 36V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 25.4mm
  • Height: 10.2mm
  • Depth: 50.8mm
  • SVHC: No SVHC (27-Jun-2018)
  • Efficiency Max: 88%
  • External Depth: 10mm
  • External Length / Height: 50mm
  • External Width: 25mm
  • Isolation Voltage: 1.5kV
  • Multiple Output Voltages: 3
  • No. of Outputs: 3Outputs
  • Operating Temperature Max: 75°C
  • Operating Temperature Min: -40°C
  • Power Rating: 30W
