Ten 8-2423WI DC DC, Wide IP, 8W, + - 15V, 0.26A TRACO Power

TRACO POWERUGS :TEN 8-2423WI Code de commande:1772192

Prix:
Prix ​​promotionnel€54,80

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (83 unité)

Documents et téléchargements

description

TRACO POWER - TEN 8-2423WI - Isolated Through Hole DC/DC Converter, ITE, 4:1, 8 W, 2 Output, 15 V, 267 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 8W
  • Output Voltage - Output 1: 15V
  • Output Current - Output 1: 267mA
  • Output Voltage - Output 2: -15V
  • Output Current - Output 2: 267mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TEN 8WI Series
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 36V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 20.8mm
  • Height: 10.2mm
  • Depth: 32mm
  • SVHC: No SVHC (27-Jun-2018)
  • Efficiency: 86%
  • External Depth: 20.3mm
  • External Length / Height: 10.2mm
  • External Width: 32mm
  • Isolation Voltage: 1.5kV
  • No. of Outputs: 2Outputs
  • Power Rating: 8W
  • Power Supply Output Type: Fixed
