Ten 8-4811 Converter, DC/DC, 8W, 5V TRACO Power

TRACO POWERUGS :TEN 8-4811 Code de commande:1205027

Prix:
Prix ​​promotionnel€43,50

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (5 unité)

Documents et téléchargements

description

TRACO POWER - TEN 8-4811 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 8 W, 1 Output, 5 V, 1.5 A

  • No. of Outputs: 1 Output
  • Output Power Max: 8W
  • Output Voltage - Output 1: 5V
  • Output Current - Output 1: 1.5A
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TEN 8 Series
  • Input Voltage DC Min: 36V
  • Input Voltage DC Max: 75V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 20.3mm
  • Height: 10.2mm
  • Depth: 32mm
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: cUL/UL 60950, IEC/EN 60950
  • Approvals & Standards: IEC, UL
  • Efficiency: 84%
  • External Depth: 20mm
  • External Length / Height: 10mm
  • External Width: 32mm
  • Isolation Voltage: 1.5kV
  • Line Regulation: 0.2%
  • Load Regulation: 0.2%
  • No. of Outputs: 1Outputs
  • Output Ripple Voltage pk-pk: 50mV
  • Output Voltage Max: 5V
  • Power Rating: 8W
  • Supply Voltage: 48V
