TEP 75-2411WI Converter, DC DC, 75W, 5V, 15A TRACO Power

TRACO POWER - TEP 75-2411WI - Isolated Chassis Mount DC/DC Converter, Railway, 4:1, 75 W, 1 Output, 5 V, 15 A

• No. of Outputs: 1 Output
• Output Power Max: 75W
• Output Voltage - Output 1: 5V
• Output Current - Output 1: 15A
• Output Voltage - Output 2: -
• Output Current - Output 2: -
• Output Voltage - Output 3: -
• Output Current - Output 3: -
• Product Range: TEP 75WI Series
• Input Voltage DC Min: 9V
• Input Voltage DC Max: 36V
• DC / DC Converter Mounting: Chassis
• DC / DC Converter Output Type: Fixed
• SVHC: No SVHC (27-Jun-2018)
• Approvals & Standards: IEC, UL
• DC / DC Converter Type: Module
• Efficiency: 88%
• External Depth: 58mm
• External Length / Height: 12.7mm
• External Width: 61mm
• Input Voltage Max: 36V
• Input Voltage Min: 9V
• Isolation Voltage: 2.25kV
• No. of Outputs: 1Outputs
• Output Current: 15A
• Output Current Max: 15A
• Output Voltage: 5V
• Output Voltage Nom.: 5V
• Power Rating: 75W
• Power Supply Output Type: Fixed
