TRACO POWER - TES 1-2422 - Isolated Surface Mount DC/DC Converter, ITE, 1:1, 1 W, 2 Output, 12 V, 40 mA
- No. of Outputs: 2 Output
- Output Power Max: 1W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 40mA
- Output Voltage - Output 2: -12V
- Output Current - Output 2: 40mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 21.6V
- Input Voltage DC Max: 26.4V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: Surface Mount DIP
- DC / DC Converter Mounting: Surface Mount Device
- Width: 8mm
- Height: 7mm
- Depth: 16.3mm
- SVHC: No SVHC (27-Jun-2018)
- Efficiency: 78%
- External Depth: 7mm
- External Length / Height: 13.7mm
- External Width: 8mm
- Isolation Voltage: 1.5kV
- No. of Outputs: 2Outputs
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Output Current - Max: -40mA
- Output Voltage +: 12V
- Output Voltage -: -12V
- Power Rating: 1W
- Supply Voltage: 24V
