THB 6-2423 DC-DC Converter, Medical, 2 O/P, 6W TRACO Power

TRACO POWERUGS :THB 6-2423 Code de commande:1772345

Prix:
Prix ​​promotionnel€74,51

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (34 unité)

Documents et téléchargements

description

TRACO POWER - THB 6-2423 - Isolated Through Hole DC/DC Converter, Medical, 2:1, 6 W, 2 Output, 15 V, 200 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 6W
  • Output Voltage - Output 1: 15V
  • Output Current - Output 1: 200mA
  • Output Voltage - Output 2: -15V
  • Output Current - Output 2: 200mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: -
  • Input Voltage DC Min: 18V
  • Input Voltage DC Max: 36V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 20.3mm
  • Height: 12mm
  • Depth: 31.8mm
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: EN 60601, IEC 60601, UL 60601
  • Approvals & Standards: IEC 60601, UL 60601
  • Efficiency: 80%
  • External Depth: 20.3mm
  • External Length / Height: 12mm
  • External Width: 31.8mm
  • Isolation Voltage: 4kV
  • No. of Outputs: 2Outputs
  • Power Rating: 6W
  • Power Supply Output Type: Fixed
