THN 15-4822WI DC/DC Converter, 15w, +/-12V, 0.625A TRACO Power

TRACO POWERUGS :THN 15-4822WI Code de commande:2080704

Prix:
Prix ​​promotionnel€61,09

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Rupture de stock

Documents et téléchargements

description

TRACO POWER - THN 15-4822WI - Isolated Through Hole DC/DC Converter, ITE, 4:1, 15 W, 2 Output, 12 V, 625 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 15W
  • Output Voltage - Output 1: 12V
  • Output Current - Output 1: 625mA
  • Output Voltage - Output 2: -12V
  • Output Current - Output 2: 625mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: -
  • Input Voltage DC Min: 18V
  • Input Voltage DC Max: 75V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 25.4mm
  • Height: 9.9mm
  • Depth: 25.4mm
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: cUL, EN, IEC, UL
  • Approvals & Standards: IEC, UL
  • Isolation Voltage: 1.5kV
  • No. of Outputs: 2Outputs
  • Power Rating: 15W
  • Supply Voltage: 48V
